Mini Dumper - SCORPION 700-800
Mini Dumper
Technical characteristics
The new Omaer Mini Dumper line also includes the SCORPION 700 and SCORPION 800 models.Designed with same quality as the small ones, the are models with bigger volumes, trapezoidal tracks and a slightly higher center of gravity, to work in every types of conditions and soils.
Robust and ductile, all the models are with self-loading shovel, with possibility to have the high or trilateral discharge of the dumper. Also on the SCORPION 700 e SCORPION 800 versions, it's available the C250 Concrete mixer kit as optional.
| 700 | 800 | |
| Engine | Honda GX270 kw 6,3 - HP 8,4 |
Honda GX390 kw 9,5 - HP 13 |
| Advancement speed | 2 velocità (2,5 km/h - 3,5 km/h) | 2 velocità (2,5 km/h - 3,5 km/h) |
| Max slope allowed (without load) | Max 30% (16°) | Max 30% (16°) |
| Max slope allowed (with load) | Max 20% (11°) | Max 20% (11°) |
| Flat load capacity | 700 kg | 800 kg |
| Slope load capacity | 500 kg | 600 kg |
| Dumper volume | 0,32 m3 | 0,32 m3 |
| Package (about) | cm. 80x198x160(h) | cm. 80x198x160(h) |
| Net weight (with shovel) | 525 kg | 540 kg |
| Net weight (high discharge) | 625 kg | 640 kg |
| Net weight (trilateral discharge) | 605 kg | 620 kg |
| Net weight (Shovel Kit) | 75 kg | 75 kg |
Data and sizes are not binding and the producer reserves itself to modify the machines without giving notice.
